Chequered Plate Flooring
Anti-slip chequered plate panels, drilled and galvanized.
What it is
Raised-pattern chequered plate panels cut, drilled and galvanized for anti-slip plant flooring, walkways and trench covers.
Applications
Materials
Finishes
Dimensional & Section Details
Engineering drawings for sizing, cross-sections and installation reference. Click any drawing to enlarge.
Buying chequered plate flooring — answered
Practical answers for procurement, engineering and EPC teams — covering specification, standards, finish, lead time and export logistics.
The diamond (or tear-drop) pattern is the universal industrial standard — it gives multi-directional slip resistance and drains effectively. Square-pattern plate is occasionally specified for aesthetic flooring in commercial buildings. Function-driven projects almost always choose diamond.
3 mm for foot-traffic decks (catwalks, mezzanines), 5 mm for trolley/cart traffic, 6 mm for forklift and material-handling. The chequered pattern adds about 1 mm to the nominal — design loads are on the base plate thickness. We share span tables on request.
Yes — we drill, edge-trim, weld stiffeners and HDG or paint to the BOQ. For trench covers we add lifting handles and hinge brackets. Site teams just bolt down — no hot work needed.
Yes — trench covers are sized to EN 124 classes A15, B125, C250, D400 (pedestrian to heavy vehicle). The cover profile, edge angle, and lifting points are configured to the trench width and traffic. We supply the calculation with the order.
HDG is the default for outdoor and industrial. For specialty applications: epoxy paint (interior wet zones, food-grade), stainless 304/316 (pharma, food, marine), and self-colour with site painting for indoor decorative use.
Manufacturing & Surface Treatment
All products are manufactured at Vajra's Howrah facility under ISO 9001:2015 quality management. In-house roll-forming, welding, galvanizing and testing — without sub-contractor dependency — ensures consistent dimensional accuracy and surface quality across export orders.
Precision Roll-Forming
CNC roll-forming lines capable of ±0.1 mm dimensional tolerance on MS, GI, SS, and aluminium sections.
Hot-Dip Galvanizing
In-house HDG plant conforming to ASTM A123 / IS 2629. Average coating: 85–140 µm. Pre-treatment: alkaline degreasing → pickling → fluxing.
Welding & Fabrication
MIG, TIG, SAW welding. Coded welders under ASME IX / IS 2825 qualification. Weld inspection by UT / DPT available.
Surface Treatment
Hot-dip galvanizing · Pre-galvanized GI · Powder coating (Tribo gun, 60–80 µm DFT) · Mill finish · Chromate passivation.
Available Material Grades
Surface Treatment Options
Manufacturing Tolerances
| Length tolerance | ±3 mm on standard lengths |
| Width tolerance | ±1 mm |
| Thickness tolerance | ±0.15 mm (IS 1079) |
| Straightness | ≤ 1 mm per 1 m |
| Galvanizing coat | 85 µm min (ASTM A123) |
| Squareness | ≤ 1 mm per 100 mm |
Global Supply & Export Documentation
Chequered Plate Flooring is exported under a documented supply chain — from factory test certification through customs clearance to door delivery. All shipments are packed to sea-freight standards with full export documentation prepared in-house.
Incoterms Available
- FOB Kolkata
- CIF Port of Destination
- CFR
- EXW Howrah Works
- DDP (on request)
Export Documents
- Commercial Invoice & Packing List
- Bill of Lading / Airway Bill
- Certificate of Origin (CoO)
- Inspection Certificate
- Phytosanitary Certificate (where applicable)
- MSDS / Material Safety Data Sheet
- Test Reports & Mill Certificates
Packaging Standards
- Wooden crate — sea-freight grade
- ISPM-15 heat-treated pallets
- Steel-strapped bales for structural sections
- VCI poly wrapping for corrosion protection
- Moisture-absorbing desiccant sachets
Compliance & Standards
Manufactured and tested to:
ISO 9001:2015 quality management system. Third-party inspection available on request (SGS, Bureau Veritas, TÜV).
Lead time: Standard stock items ship within 7–10 working days after order confirmation. Custom fabricated quantities: 15–25 working days. Express production available — contact our export desk.
Countries importing Industrial Flooring from India
Industrial Flooring Systems is in active demand across these markets. Click a country to see named importers, city-level volumes, and customs shipment intelligence.
Sectors That Specify This Product
This product line is specified by procurement and engineering teams across the following sectors. Each industry page lists the specific product requirements, typical standards, and export documentation relevant to that buyer profile.
Power & Energy
Utilities & IPPs
Construction
EPC & civil contractors
Oil & Gas
Refineries & terminals
Manufacturing
Heavy process industry
Application engineering support: Our technical sales team provides product selection, load calculation references, and specification assistance for EPC, PMC, and procurement teams. Available for onsite consultation in major project cities.
Download Technical Documentation
Technical Datasheet
PDF · Engineering specifications · Export-ready
Complete engineering datasheet for Chequered Plate Flooring — dimensional data, material grades, tolerances, applicable standards, and export compliance information.
Free · No registration required · Industrial Flooring datasheet
Request a quote for chequered plate flooring.
Send drawings, a BOQ, or a simple description. You'll get a structured quotation covering specification, finish, lead time and Incoterms — from the manufacturer, not a middleman.
- MTC · COO · inspection reports
- ±0.01 mm precision · in-house QA
- FOB · CIF · CFR to all major ports
